11-inch R1 Tablet
Rockchip RK3588S ARM Tablet with 6Tops NPU & 8K Display
USD $199.00 – $204.90
Fast shipping & 1W+ Sold
Rockchip RK3588S Quad-Core A76+A55 ARM Mali-G610 MC4, 6.0 TOPs NPU
∞
Sold
7x24 Hours
Technical Support
1 V 1
Service
Product Highlights:
- 8nm process, Quad-core ARM 64-bit, 4*Cortex-A76@2.2GHz + 4*Cortex-A55@1.8GHz
- ARM Mali-G610 MC4, embedded high performance 2D image acceleration module
- 6.0 TOPs NPU, enable various AI applications
- 8K video codec, 8K@60fps display out
- Android12(Default) Android11/13/14(Optional), Ubuntu22.04 / Debian11 / Buildroot UOS / KyLinOS / HarmonyOS
Matching package
USD $189.00 – $194.90
Fast shipping & 1W+ Sold
USD $299.00 – $304.90
Fast shipping & 1W+ Sold
11-inch R1 Tablet
Key features
- 8nm process, quad-core Cortex-A76 + quad-core Cortex-A55
- ARM Mali-G610 MC4 GPU, embedded high performance 2D image acceleration module
- 6.0 TOPs NPU, enable various AI applications
- 8K video codec, 8K@60fps display out
- Rich Display Interface, multi-screen display
- Super 32MP ISP with with HDR&3DNR, multi-camera inputs
- Android12(Default) Android11/13/14(Optional), Ubuntu22.04 / Debian11 / Buildroot UOS / KyLinOS / HarmonyOS
DETAIL SPEC
| Display & Touch Screen | Display Size | 11 inch IPS LCD |
| Max. Resolution | 2000 x 1200 | |
| Luminance (cd/m2) | 350 | |
| Touch Type | Incell capacitive touch | |
| Point of Touch | 10 point | |
| System | CPU | Rockchip RK3588S, 8nm process Quad-core ARM 64-bit 4*Cortex-A76@2.2GHz + 4*Cortex-A55@1.8GHz |
| GPU | ARM Mali-G610 MC4 OpenGL ES 1.1/2.0/3.1/3.2 OpenCL 1.1/1.2/2.0 Vulkan 1.1/1.2 High performance 2D image acceleration | |
| NPU | Triple-core NPU, 6 TOPS Performance Support int4/int8/int16/FP16/BF16/TF32 acceleration Enable various AI applications | |
| VPU | Video Decoding: 8K@60fps: H.265/VP9/AVS2 8K@30fps: H.264 AVC/MVC 4K@60fps: AV1 1080P@60fps: MPEG-2/-1/VC-1/VP8 Video Encoding: 8K@30fps: H.265/H.264 | |
| RAM | 8GB LPDDR4X (option:16/32GB) 2133MHz, 64-bit | |
| Storage | 128GB (option: 64/256/512GB) Mirco SD card expansion | |
| Camera | Front | 5MP |
| Rear | 13MP, Auto focus, Flash | |
| Wireless | Wi-Fi | WiFi-6 IEEE 802.11a/b/g/n/ac/ax |
| Bluetooth | Bluetooth 5.2 BLE | |
| Audio | Headphone | USB Type-C Digital headphone |
| Speaker | 8Ω/1.3W, quad speakers | |
| Mic | Supported | |
| Sensor | IMU | 3-axis accelerometer and 3-axis gyroscope |
| Light | Ambient light sensor | |
| Hall | Supported | |
| Other Function | RTC | Supported |
| Vibrator | Supported | |
| I/O Interface | USB Type-C | USB3.1 OTG, DP ALT, PD |
| TF Card | Mirco TF Card | |
| Button | Power/Vol+/Vol- | |
| Operating System | Android | Android12(Default) Android11/13/14(Optional) |
| Linux | Ubuntu22.04 / Debian11 / Buildroot | |
| Chinese OS | UOS / KyLinOS / HarmonyOS | |
| Power Consumption | USB Type-C | USB-C Adapter, 5V/3A, 9V/2.22A, 12V/1.67A(20W) |
| Battery | 3.8V/7500mAH, 6-8Hours | |
| Construction | Chassis Material | Integrated aluminum alloy |
| Color (Front/Back) | Silver, gray, blue, etc | |
| Mounting | Handheld or desktop | |
| Mechanical | Dimension | 258.5 x 162.1 x 9mm |
| Weight | 1.05 lb ( 476g ) | |
| Ambient | Operating Temperature | 0℃～50℃ |
| Storage Temperature | -20℃～70℃ | |
| Operating Humidity | 10%～90% (Non condensation) |
