Kiwi Pi-P2
Quad-core ARM 64-bit, 4*Cortex-A76@2.2GHz + 4*Cortex-A55@1.8GHz
USD $239.00 – $278.99
Fast shipping & 1W+ Sold
Rockchip RK3588 Quad-Core A76+A55 ARM Mali-G610 MC4，6.0 TOPs NPU
∞
Sold
7x24 Hours
Technical Support
1 V 1
Service
Product Highlights:
- 8nm process, Quad-core ARM 64-bit, 4*Cortex-A76@2.2GHz + 4*Cortex-A55@1.8GHz
- ARM Mali-G610 MC4, embedded high performance 2D image acceleration module
- 6.0 TOPs NPU, enable various AI applications
- 8K video codec, 8K@60fps display out
- Linux 5.10 (option:Linux6.10), Android12, Debian11, Ubuntu22.04
Matching package
USD $99.00 – $178.99
Fast shipping & 1W+ Sold
Kiwi Pi-P2
Key features
- 8nm process, Quad-core ARM 64-bit, 4Cortex-A76@2.2GHz + 4Cortex-A55@1.8GHz
- ARM Mali-G610 MC4, embedded high performance 2D image acceleration module
- 6.0 TOPs NPU, enable various AI applications
- 8K video codec, 8K@60fps display out
- Rich Display Interface, multi-screen display
- Super 32MP ISP with with HDR&3DNR, multi-camera inputs
- Rich high-speed interfaces (PCIe, TYPE-C，SATA, Gigabit ethernet)
- Linux 5.10 (option:Linux6.10), Android12, Debian11, Ubuntu22.04
DETAIL SPEC
| CPU | Rockchip RK3588, 8nm process Quad-core ARM 64-bit 4*Cortex-A76@2.2GHz + 4*Cortex-A55@1.8GHz |
| GPU | ARM Mali-G610 MC4 OpenGL ES 1.1/2.0/3.1/3.2 OpenCL 1.1/1.2/2.0 Vulkan 1.1/1.2 High performance 2D image acceleration |
| NPU | Triple-core NPU, 6 TOPS Performance Support int4/int8/int16/FP16/BF16/TF32 acceleration Enable various AI applications |
| VPU | Video Decoding: 8K@60fps: H.265/VP9/AVS2 8K@30fps: H.264 AVC/MVC 4K@60fps: AV1 1080P@60fps: MPEG-2/-1/VC-1/VP8 Video Encoding: 8K@30fps: H.265/H.264 |
| DDR | LPDDR4X 8GB (option: 4/16/32GB) 2133MHz, 64-bit |
| Storage | eMMC 64GB (Option:128GB/256GB/512GB) MicroSD (TF) Card Slot |
| USB | 1*Type-C (Full funtion:USB3.1-OTG,DP ALT,PD) 4*USB 3.0 Host 2*USB 2.0 Host |
| Serial Ports | 2xRS-232 1xRS-485 |
| Video Output | HDMl2.1(Maximum resolution 8K@60fps) Type-C DP1.4(maximum resolution 8K@30fps) Display Port DP 1.4 Mipi-DSl 4-Lane(maximum resolution 2560*1600@60fps) |
| Video Iutput | 4* MIP|-CS| 4Lane HDMI RX 2.0 |
| HDMI | 1*HDMI TX 2.1, 1*HDMI RX 2.0 |
| Wireless | WiFi 6 (IEEE802.11 a/b/g/n/ac/ax up to 600.4Mbps) BT5.4 2.4Ghz and 5Ghz band channels, 2T2R |
| Ethernet | 2x1000Mbps RJ45 |
| Audio | 3.5mm headphone jack with stereo audio output and mic input On board mic input |
| Power Supply | DC in 12V/2A |
| Supported OS | Linux 5.10 (option:Linux6.10) Android12, Debian11, Ubuntu22.04 |
