Kiwi Pi-T2
Quad-core ARM 64-bit, 4*Cortex-A76@2.2GHz + 4*Cortex-A55@1.8GHz
USD $99.00 – $178.99
Fast Shipping & 1W+ Sold
Rockchip RK3588 Quad-Core A76+A55 ARM Mali-G610 MC4 , 6.0 TOPs NPU
∞
Sold
7x24 Hours
Technical Support
1 V 1
Service
Product Highlights:
- 8nm process, Quad-core ARM 64-bit, 4*Cortex-A76@2.2GHz + 4*Cortex-A55@1.8GHz
- ARM Mali-G610 MC4, embedded high performance 2D image acceleration module
- 6.0 TOPs NPU, enable various AI applications
- 8K video codec, 8K@60fps display out
- Linux 5.10 (option:Linux6.10), Android12, Debian11, Ubuntu22.04
Kiwi Pi-T2
Key features
- 8nm process, quad-core Cortex-A76 + quad-core Cortex-A55
- ARM Mali-G610 MC4 GPU, embedded high performance 2D image acceleration module
- 6.0 TOPs NPU, enable various AI applications
- 8K video codec, 8K@60fps display out
- Rich Expand IO (2Type-C OTG, 2USB2.0 Host，2HDMI/eDP TX, 1HDMI RX，2MIPI-DSI 4Lane, 1MIPI-CSI 4Lane
- Super 32MP ISP with with HDR&3DNR, multi-camera inputs
- Linux 5.10 (option:Linux6.10), Android 12 / Ubuntu22.04 / Debian11
DETAIL SPEC
| CPU | Rockchip RK3588, 8nm process Quad-core ARM 64-bit 4*Cortex-A76@2.2GHz + 4*Cortex-A55@1.8GHz |
| GPU | ARM Mali-G610 MC4 OpenGL ES 1.1/2.0/3.1/3.2 OpenCL 1.1/1.2/2.0 Vulkan 1.1/1.2 High performance 2D image acceleration |
| NPU | Triple-core NPU, 6 TOPS Performance Support int4/int8/int16/FP16/BF16/TF32 acceleration Enable various AI applications |
| VPU | Video Decoding: 8K@60fps: H.265/VP9/AVS2 8K@30fps: H.264 AVC/MVC 4K@60fps: AV1 1080P@60fps: MPEG-2/-1/VC-1/VP8 Video Encoding: 8K@30fps: H.265/H.264 Support 32 channels of 1080P@30fps decoding and 16 channels of 1080P@30fps encoding at the same time |
| DDR | LPDDR4X 8GB (option: 4/16/32GB) 2133MHz, 64-bit |
| eMMC5.1 | 128GB (option: 64/256/512GB) |
| Expand IO | 314Pin MXM Connector Supports: 2*Type-C OTG, 2*USB2.0 Host 2*HDMI/eDP TX, 1*HDMI RX 2*MIPI-DSI 4Lane, 1*MIPI-CSI 4Lane 3*PCIe2.0/SATA3.0, 1*PCIe3.0x4 2*SDMMC, 2*Gmac Most I/O can be programmed as GPIO/I2C/UART/SPI, etc |
| Power Supply | DC 4V/5A |
| OS | Linux 5.10 (option:Linux6.10) Android12/Ubuntu22.04/Debian11 |
| Dimensions | 82mm × 55mm |
| Environmental Conditions | Operating Temperature: 0°C ~ 60°C Storage Temperature: -20°C ~ 70°C Humidity: 10% ~ 90% (non-condensing) |
