Product Highlights:
- Octa-core Cortex-A53 up to 1.5GHz
- PowerVR G6110 GPU
- 4K UHD H265/H264 decoder
- FHD panel display
- SmartPhone connection support
Quote
Matching package
USD Bulk Pricing
Fast Shipping & 1W+ Sold
USD Bulk Pricing
Fast Shipping & 1W+ Sold
Rockchip PX5
Key features
- Octa-core Cortex-A53 up to 1.5GHz
- PowerVR G6110 GPU
- DDR3/DDR3L/LPDDR2/LPDDR3
- 4K UHD H265/H264 decoder
- FHD panel display
- ADAS Algorithm support
- SmartPhone connection support
- Fast Reverse view
The PX5 processor is a power-efficient, high-performance solution designed for in-vehicle infotainment systems. It supports Android operating system and is based on the ARM Cortex architecture, combining an octa-core Cortex-A53 CPU with a dedicated NEON coprocessor. Equipped with advanced hardware engines, it delivers optimized performance for premium applications. The PX5 can decode nearly all formats, including 4Kx2K at 30fps H.264, H.265, and supports H.264/MVC/VP8 encoding at 1080p@30fps.
It also features a high-quality JPEG encoder/decoder, along with specialized image pre- and post-processing units. A built-in 3D GPU ensures full compatibility with OpenGL ES 3.1, OpenCL 1.2, and DirectX 9.3. Additionally, a dedicated 2D hardware engine with MMU enhances display output and ensures smooth operation. The PX5 supports high-performance external memory interfaces such as DDR3, DDR3L, LPDDR2, and LPDDR3, capable of handling demanding bandwidth requirements. It also offers a comprehensive range of peripheral interfaces, enabling versatile and flexible application development.
DETAIL SPEC
| Process | 28nm |
| CPU | Octa-Core 64bit Cortex-A53,up to 1.5GHz |
| GPU | PowerVR G6110 GPU |
| Support OpenGL ES 1.1/2.0/3.1, OpenCL, DirectX9.3 | |
| High performance dedicated 2D processor | |
| Multi-Media | 4K H265 60fps/H264 25fps video decoders |
| 1080P other video decoders (VC-1, MPEG-1/2/4, VP8) | |
| 1080P video encoder for H.264 and VP8 | |
| Display | Support RGB/LVDS/MIPI-DSI/eDP interface, up to 2048×1536 resolution |
| HDMI 2.0 for 4K@60Hz with HDCP 1.4/2.2 | |
| Security | ARM TrustZone (TEE), Secure Video Path, Cipher Engine, Secure boot |
| Memory | 32bit DDR3-1600/DDR3L-1600/LPDDR3-1333 |
| Support MLC NAND, eMMC 4.51, Serial SPI Flash booting | |
| Connectivity | Embedded 8M ISP, MIPI CSI-2 and DVP interface |
| Dual SDIO 3.0 interface | |
| TS in/CSA2.0 | |
| Embed HDMI、Ethernet MAC 、S/PDIF、USB,I2C,I2S ,UART,SPI | |
| Package | BGA453 19X19, 0.8mm pitch |
| State | MP Now |
