RK3576
Octa-core 64-bit high-performance ARM processor
USD Bulk Pricing
Fast Shipping & 1W+ Sold
Rockchip RK3576 Quad-Cortex-A72+ Quad-Core A53 ARM G52 MC3
∞
Sold
7x24 Hours
Technical Support
1 V 1
Service
Product Highlights:
- CPU：Quad-Core Cortex-A72 paired with Quad-Core Cortex-A53, reaching speeds up to 2.2GHz.
- GPU：ARM G52 MC3 for robust graphics performance.
- PQ Engine: Rockchip’s specialized Picture Quality Engine supporting HDR, ACM, DCI, and more.
- Display Options: Supports multiple interfaces including DisplayPort, MIPI, eDP, HDMI, RGB, and EBC, enabling various display sources.
- Video Capabilities: Decodes 8K at 30fps using H.264, H.265, VP9, AV2, and AVS2; encodes 4K at 60fps with H.264 and H.265.
Quote
Matching package
USD Bulk Pricing
Fast Shipping & 1W+ Sold
USD Bulk Pricing
Fast Shipping & 1W+ Sold
Rockchip RK3576
Standard instructions for use
- The iFPD series encompasses a range of cutting-edge solutions, including Industrial Control & Gateway, Cloud Connectivity Modules, Facial Recognition Technologies, Intelligent Central Management Systems, and Commercial Display Units.
Key features
- Equipped with an octa-core 64-bit ARM processor that delivers high performance, featuring a wide range of high-speed interfaces such as PCIe, USB 3.0, SATA, and GMAC, as well as low-speed interfaces including CAN FD, DSMC, UART, SPI, I2C, and I3C. This allows for rapid deployment of a versatile, multi-application platform.
- Incorporates a proprietary 6 TOPS AI Neural Processing Unit (NPU) that offers efficient support for various AI-driven tasks.
- Features a comprehensive display interface and a powerful GPU capable of supporting three independent displays from different sources.
- Boasts advanced image processing, video encoding and decoding, and audio handling capabilities, enabling interactive visual and voice recognition functionalities.
- Supports standard Android and Linux SDKs, as well as Chinese Operating Systems.
Rockchip RK3576 is a powerful octa-core 64-bit ARM processor designed for high-performance industrial and commercial applications. Featuring a 6 TOPS self-developed AI NPU, it enables advanced AI functionalities such as facial recognition, intelligent central control, and interactive voice recognition. With rich high-speed interfaces (PCIe, USB 3.0, SATA, GMAC) and low-speed interfaces (CAN FD, UART, SPI, I2C, I3C), the RK3576 ensures seamless connectivity and rapid deployment across multiple applications. Its high-performance GPU supports triple-display output with different sources, making it ideal for iFPD, industrial control, cloud terminals, and commercial displays. The chip also boasts strong multimedia capabilities, including video encoding/decoding and audio processing, while supporting Android and Linux for flexible development.
DETAIL SPEC
| CPU | Featuring a powerful combination of a quad-core Cortex-A72 and a quad-core Cortex-A53, reaching speeds of up to 2.2GHz. |
| GPU | Featuring the ARM G52 MC3 GPU. |
| NPU | 6TOPS* RKNN |
| PQ | Advanced Image Clarity System (HDR, ACM, DCI, and more) |
| Display | Support for multiple displays with various interfaces including DisplayPort, MIPI, eDP, HDMI, RGB, and EBC, accommodating different source devices seamlessly. |
| Memory | 32-bit LPDDR4/4x and LPDDR5 memory technologies with enhanced performance. |
| UFS 2.0 (dual-lane), eMMC 5.1, SPI NOR/NAND flash memory | |
| Video | 8K/30 fps H.264/H.265/VP9/AV2/AVS2 Decoder supporting |
| 4K60Hz High-Resolution Video Encoder Supporting H.264/H.265 | |
| Camera | 116M ISP with HDR supporting up to 120dB of dynamic range. |
| The technical specifications include MIPI CSI-2 configured with CDPHY as a 4-lane setup, DPHY operating with either two 4-lane or four 2-lane configurations, along with DVP. | |
| Interface | The system includes five SAI interfaces, each equipped with 7 transmission and 7 reception lanes, with each lane supporting 8-channel I2S, PCM, or TDM formats. |
| 2 PCM (2*8-ch) | |
| 2 S/PDIF TX and 1 S/PDIF RX | |
| ASRC | |
| Supports USB 3.0 DRD with Alt Mode and DisplayPort. | |
| USB3.0 DRD/PCIe 2.1 RC/SATA3 | |
| PCIe 2.1 RC/SATA3 | |
| RGMIIx2 | |
| Supports CAN FD, DSMC | |
| Supports UART, SPI, PWM, I2C, SAR-ADC |
