RKNanoC
100MHz Cortex-M3
USD Bulk Pricing
Fast Shipping & 1W+ Sold
Rockchip RKNanoC 100MHz Cortex-M3
Built-in 128KB IRAM，96KB DRAM
∞
Sold
7x24 Hours
Technical Support
1 V 1
Service
Product Highlights:
- Processor: Dual-core ARM Cortex-A7 running up to 1.0GHz
- Graphics: ARM Mali-400MP GPU supporting OpenGL ES 1.1 and 2.0, complemented by a high-performance dedicated 2D engine
- Display Outputs: HDMI 1.4 with HDCP 1.3 compliance, and CVBS output
- Memory Options: 16-bit DDR3-1066/DDR3L-1066, alongside MLC NAND, eMMC 4.5, SPI NOR, and NAND Flash storage
- Connectivity Features: Built-in CVBS, HDMI, Ethernet MAC, S/PDIF, Audio DAC, and USB ports USB
Quote
Matching package
USD Bulk Pricing
Fast Shipping & 1W+ Sold
USD Bulk Pricing
Fast Shipping & 1W+ Sold
Rockchip RKNanoC
Key features
- Single-core Cortex-M3
- Built-in
- Multi-format audio decoder
- Built-in Power Management
- Low power consumption
The Rockchip RKnanoC is an affordable, energy-efficient digital multimedia chip engineered around an ARM low-power processor core with integrated hardware acceleration. It is tailored for portable audio devices like MP3 players.
The RKnanoC supports decoding a broad range of audio formats, including MP3, WMA, OGG, FLAC, and AAC. Thanks to its built-in audio hardware accelerator, it can perform audio decoding at very low system clock speeds, significantly reducing power consumption. Additionally, it offers a comprehensive set of peripheral interfaces, enabling versatile applications such as NAND Flash memory, LCD controllers, USB On-The-Go, SD/MMC cards, I2C, I2S, SPI, UART, and PWM, making it highly adaptable for various device integrations.
DETAIL SPEC
| CPU | 100MHz Cortex-M3 |
| Memory | Built-in 128KB IRAM，96KB DRAM |
| Boot from SPI NOR flash and MLC NAND, support SD/MMC Card | |
| Audio DAC | Built-in Lower power cap-less Audio-DAC |
| Display | Built-in Power Management |
| 1 USB 2.0 OTG，1 SD/MMC | |
| 1 SPI，1 I2S，1 UART，1 I2C | |
| Display | MCU LCD Interface up to 220*176 |
| Audio | Multi-format audio decoder |
| Video | XVID up to 220*176 (Need RKTOOL to translate) |
| OS | RKOS |
