RKNanoD
Dual-Core ARM Cortex-M3,up to 400MHz
USD Bulk Pricing
Fast Shipping & 1W+ Sold
Rockchip RKNanoD Dual-core Cortex-M3
Built-in 1M Byte SRAM
∞
Sold
7x24 Hours
Technical Support
1 V 1
Service
Product Highlights:
- CPU: Dual-Core ARM Cortex-A7 processor, capable of reaching up to 1.0GHz.
- GPU: ARM Mali-400MP graphics processor supporting OpenGL ES 1.1 and 2.0, equipped with a high-performance dedicated 2D processor
- Display: HDMI 1.4 output with HDCP 1.3 support, along with CVBS output.
- Memory: 16-bit DDR3-1066/DDR3L-1066, MLC NAND flash memory, eMMC 4.5, SPI NOR flash, and NAND flash.
- Connectivity: Built-in CVBS, HDMI, Ethernet MAC, S/PDIF, Audio DAC, and USB ports. USB
Quote
Matching package
USD Bulk Pricing
Fast Shipping & 1W+ Sold
USD Bulk Pricing
Fast Shipping & 1W+ Sold
USD Bulk Pricing
Fast Shipping & 1W+ Sold
Rockchip RKNanoD
Key features
- Dual-core Cortex-M3
- Built-in 1M Byte SRAM
- Multi-format audio decoder
- 192kHz/24-bit audio codec
- Low power consumption
Rockchip RKNanoD is a small, affordable chip that saves energy. It uses ARM Cortex-M3 technology and has a built-in audio decoding part. It is mainly used in multimedia devices and smart gadgets. It offers many connections like VOP, USB, SD card, I2C, I2S, SPI, PWM, and others, making it useful for many different projects.
DETAIL SPEC
| CPU | Dual-Core ARM Cortex-M3,up to 400MHz |
| Memory | Built-in 1M Byte SRAM |
| eMMC，SPI NOR FLASH， SPI NAND FLASH， SD Card | |
| Audio CODEC | Built-in 24bit/192KHz ACODEC，2 x LineIn，2 x MIC，Lineout，HPout |
| Connectivity | SDMMC，SDIO，USB2.0 OTG，E-ink I/F，LCD i8080 I/F，6 x UART，2 x SPI，1 x SFC 3 x I2C，2 x I2S，5 x PWM，8 x ADC，56 x GPIO |
| Display | Max to 320×240 TFT LCD |
| Audio | Multi-format audio decoder |
| Video | XVID up to 220*176 (Need RKTOOL to translate) |
| OS | RKOS， FreeRTOS |
